If the maximum actual pressure during identification is higher than the actual
setting for the minimum output, the measured value is used as new minimum
profile output for the pressure.
4.119.2 Description of the mask
The identified values of the minimum velocity output for the ejector, mold, noz-
zle and inject are displayed.
Fig.4-124: Mask "Identification of minimum profile output"
4.119.3 Description of the elements
Start auto speed calibration
Field Description
Do Calibration
Starts identification of minimum profile output
for the desired movement.
4.120
Display and user settings
4.120.1 Purpose
This mask is used to set the display parameters as well as for user login and
for changing user passwords.
KePlast.HMI.KVB
Description of the operating masks
© KEBA 2016
User's manual V3.05 231
