Heat settings
Field Description
Number of heating zones The number of existing heating zones is specified here.
Max. temperature
The maximal accepted temperature of the heating zones can be
specified here (applies for all heating zones).
If one heating zone exeeds this temperature, the heating of all
zones will be turned off. Only if the temperature of all zones is
lower than the maximal accepted temperature, the heating can be
activated again.
Observation temperature
difference
Parameter is relevant for heating element supervervision.
Within a defined time (default 180 seconds) the temperature of the
heating element must increase at least for the configured obser-
vation temperature difference when heating output is 100%.
Otherwise an alarm will be raised.
Cycle time Cycle duration of PWM-impulses for heating up every zone.
Minimal pulse time Minimal pulse time which is used for heating up every zone.
Motors
Field Description
Motor wye on time
The duration of the motor's wye operation at delta-wye start-up is
specified here.
Motor delta-wye delay time
The duration specified here represents the time between the end
of the wye operation and the start of the delta operation of the
motor.
Motor overload mode
Defines whether a normally closed or normally open switch is used
for detectring motor overload.
● Normally closed: Alarm will be raised if digital input becomes
False.
● Normal open: Alarm will be raised if digital input becomes
True.
4.96 Maschine equipment - Tab2
4.96.1 Purpose
This mask allows additional specifying for machine equipment.
4.96.2 Description of the mask
This mask is divided into the following sections:
● Oil filter
● Oil level
● Servo valve inject
Description of the operating masks
KePlast.HMI.KVB
© KEBA 2016
User's manual V3.05194
