Keba Kemro K2 User Manual

4.104.3 Description of the elements
Axis for calibration
Field Description
Axis for pump n calibration
Allows the selection of the axis that is used for
calibration of pump n.
● Manual = manual calibration
● Injection = injection axis is used
● Mold = mold axis is used
● Ejector = ejector axis is used
Auto calibration settings
Field Description
Maximum measure position relative to screw
stroke
Maximum position relative to screw stroke dur-
ing velocity calibration. It is displayed in per-
cent of the cylinder length.
Maximum measure position relative to mold
stroke
Maximum position relative to mold stroke dur-
ing velocity calibration. It is displayed in per-
cent of the cylinder length.
Maximum measure position relative to ejector
stroke
Maximum position relative to ejector stroke
during velocity calibration. It is displayed in per-
cent of the cylinder length.
Auto pressure calibration
Field Description
Max. velocity output during pressure calibra-
tion
Maximum output voltage for velocity during
pressure calibration.
Delay between pump pressure calib steps
Delay time between two following pressure cal-
ibration steps. This delaytime is considered for
pump pressure and servo pressure calibration.
4.105 Calibration Trancducer - Tab1
4.105.1 Purpose
This mask is used to manually calibrate the transducers for the ejector, the
mold and injection unit.
4.105.2 Description of the mask
The manual calibration of a sensor is done by entering values in a linearization
table.
Description of the operating masks
KePlast.HMI.KVB
© KEBA 2016
User's manual V3.05208
