Photosensor
Field Description
Use photo sensor Activation of a photosensor for part detection.
Photosensor timeout If the monitoring time is exceeded, an error is triggered.
Euromap
WARNING!
The system (hardware and software) only meets category B according to
EN ISO 13849-1. Thus it is not intended for usage in safety-relevant control ap-
plications in the field of personal safety (e.g. emergency stop).
To implement potentially necessary safety-relevants control tasks, always use
additional external safety devices according to EN ISO 13849-1 that are intended
for the particular purpose and meet the necessary functional safety.
For further information see EN ISO 13849-1 and refer to chapter "EC directives
and standards" in the manuals for a list of norms applying to the product.
The safety notices for the installation and commissioning of the product can be
found in the user manuals of the components or in the system manual and must
be read and observed before installation or commissioning.
The user manual must be kept throughout the entire service life of the product.
WARNING!
Following signals of the Euromap interface are not handled by the software.
● Emergency stop of machine
● Safety devices of machine
Field Description
Robot interface
Here you can select the required Euromap robot interface.
● Not used
● Euromap 12
● Euromap 67
● User defined: all configured endpoints for Euromap will be
used. Necessary enpoints according to Euromap specification
which are not available will be ignored.
Imterm. mold open pos.
● No
● Use= the signal "Mold area free" is ignored for mold open
movement after the configured intermediate position is
reached. As long as the intermediate position is not reached
during the mold open movement, the signal "Mold are free"
must be TRUE.
Description of the operating masks KePlast.HMI.KVB
© KEBA 2016
User's manual V3.05130
