Information
In general, it is recommended to execute the single auto calibration steps in
the same order as they are performed when executing all auto calibration
steps automatically. For single auto calibration, following rules must be ad-
hered.
● Calibration of 'Injection' in group 'Transducer' has to be executed before
calibration of 'Injection' in group 'Closed loop'.
● If a servo valve is available, 'Pump pressure' and 'Pump velocity' have to
be calibrated before 'Servo press fwd' and 'Servo vel fwd'.
● Control system must not reboot between the calibration steps 'Servo
press fwd' and 'Servo vel fwd'.
Transducer
Field Description
Ejector
Ejector calibration:
Display of the ejector stroke.
Mold
Mold calibration:
Display of the mold stroke
Nozzle
Nozzle calibration
Display of the nozzle stroke.
Injection
Inject calibration:
Display of injection velocity
Velocity
Field Description
Pump n velocity Pump flow calibration for the n-th pump
Servo velocity forward
(optional)
Flow calibration servo valve.
Only displayed if a servo valve is available.
RPM
Screw torque calibration:
Display of the maximum possible torque.
Input field is used to limit the maximum possible torque during
calibration. If value is set to '0', the maximum torque will be de-
tected automatically. If an other value is set, this value won't be
exceeded during calibration.
Pressure
Field Description
Pump n pressure Pump pressure calibration for the n-th pump.
Servo pressure forward
(optional)
Pressure calibration servo valve.
Only displayed if a servo valve is available.
Description of the operating masks KePlast.HMI.KVB
© KEBA 2016
User's manual V3.05206
