Field Description
High pressure keep time
After mold close movement has finished, high pressure stage
stays active for this time.
Check ejector safety plate
This option can be activated to detect a break of the ejector rod by
checking a digital input which is integrated in the mold. If this func-
tion is activated the digital input must be true, otherwise all mold
close movements are locked.
This field is only displayed if the digital input for ejector safety plate
is configured.
Use lock pin Disables / Enables lock pin movement.
Hold lock pin out during
slide
During slide table movement, the lock pin is hold in position "out"
actively.
Hold lock pin out during ro-
tate
During rotary table movement, the lock pin is hold in position "out"
actively.
Maximum movement time
Field Description
Max. close time
The left field Actual displays the current time for mold close move-
ment. The maximum permitted time until the mold is completely
closed is specified in field Limit. If this time is exceeded an alarm
will be triggered and the cycle is stopped. The difference between
the two values is shown in the right field Differ.
Max. open time
The left field Actual displays the current time for mold open move-
ment. The maximum permitted time until the mold is completely
opened is specified in field Limit. If this time is exceeded an alarm
will be triggered and the cycle is stopped. The difference between
the two values is shown in the right field Differ.
Max. lock time
The duration of Mold HighPressure (last profile stage in mold pro-
file) is shown in the left field Actual. The monitoring time is entered
in field Limit. The difference between the two values is shown in
the right field Differ.
Movement start delay
Field Description
Close delay The delay time for the mold close movement is adjusted here.
Open delay The delay time for the mold open movement is adjusted here.
Setup mode output
Field Description
Setup mode output close
Pressure and velocity output for the mold close movement in setup
mode.
Setup mode output open
Pressure and velocity output for the mold open movement in setup
mode.
KePlast.HMI.KVB Description of the operating masks
© KEBA 2016
User's manual V3.05 49
