Ramp profile output
Field Description
Max. ramp close
The maximum ramp (pressure, velocity) for the mold close move-
ment is adjusted here.
Max. ramp open
The maximum ramp (pressure, velocity) for the mold open move-
ment is adjusted here.
Mold adjust forward
The maximum ramp (pressure, velocity) for the mold height adjust
forward movement is adjusted here.
Mold adjust backward
The maximum ramp (pressure, velocity) for the mold height adjust
backward movement is adjusted here.
Tolerance
Field Description
Endposition tolerance Tolerance for detecting mold open endposition. Tolerance is +/-.
Delay times
Field Description
Close delay
Field Pump on specifies the time that is waited between the start
of the 'Mold close' movement and the activation of the hydraulic
pump.
Field Valve off determines the time that is waited between the end
of the movement 'Mold close' and the closing of the control valve
in order to release the remaining pressure.
Open delay
Field Pump on specifies the time that is waited between the start
of the 'Mold open' movement and the activation of the hydraulic
pump.
Field Valve off determines the time that is waited between the end
of the movement 'Mold open' and the closing of the control valve
in order to release the remaining pressure.
Mold height
Field Description
Min. mold height
The specification of minimum mold height (minimum distance be-
tween fixed and moving plate in closed state).
Max. mold height
The specification of maximum mold height (maximum distance
between fixed and moving plate in closed state).
Mold height origin
Sets the current mold height.
Once this check box has been selected, the value set is adopted
as the new actual value.
Mold height calculate posi-
tion
Specifies the second value for calculation (distance to position
Mold height origin), which is required for the calibration of the au-
tomatic mold adjust in pressure and position mode. The value for
Mold height origin must have been set already.
By selecting this check box the caclulation of distance/impulse for
the mold height adjust is started. This step is necessary before
automatic mold height adjust is executed.
KePlast.HMI.KVB Description of the operating masks
© KEBA 2016
User's manual V3.05 53
