365-575-102 Circuit Order: NTP-008
Issue 8.0, July 2002 Page 9 of 12
13. Instruct the technician at the East node to:
a. Change the lightguide buildout as
necessary on the 1W receive fiber.
b. Connect it to 1W RCVR circuit pack.
c. Verify the RCVR (line 1W) does not
show an incoming OC-48 LOS condi-
tion by obtaining an Active Alarms
and Status Report at the CIT located
at the East node.
—
14. At the CIT, select
CONFIGURATION-Retrieve-Map-Ring
command to obtain a Ring Map Report and verify
that the "new node" has been added to the ring
as intended. (Comm Stat should indicate good.)
—
!
CAUTION:
Incorrect setting of the timing option could result in a service
interruption in certain applications. Be certain that the timing option for
the new bay is set to be consistent with the rest of the ring and to be
consistent with the intended application. The bay defaults to “free
running mode” when it is initially turned up. Provisionable timing
options are discussed in Section 5 of this User/Service Manual.
DOITEMSBELOWINORDERLISTED....... FORDETAILS,GOTO
