365-575-102 CircuitOrder:
Issue 8.0, July 2002 Page 1 of 6
NTP-016
Change an OC-3/IS-3 Link From 1+1 to 0x1
Protection Mode
DOITEMSBELOWINORDERLISTED........ FORDETAILS,GOTO
1. Overview: The steps in this procedure enable you to change an OC-3 Low
Speed optical link from 1+1 protection mode to 0x1 protection mode without
causing a service impairment. Tasks are performed on two separate NEs (for
example; Node A, an FT-2000, and Node B). Node B can be another
FT-2000, DDM-2000, or other vendor equipment. The process is as follows:
1. At Node A, switch traffic from Protection pack to Service pack.
2. At Node B, switch traffic from Protection pack to Service pack.
3. At Node B, change Protection mode from 1+1to0x1.
4. At Node A, change Protection mode from 1+1to0x1.
NOTE:
The “Service slot” has an _a (e.g., 1a, 2a, 3a, etc) slot address. The
“Protection slot” has an _b (e.g., 1b, 2b, 3b, etc) slot address.
Required Test Equipment:
Craft Interface Terminal (CIT)
Wrist Strap
!
WARNING:
Unterminated optical connectors may emit invisible laser radiation. Eye
damage may occur if the beam is viewed directly or with improper optical
instruments. Avoid direct exposure to beam.
To Next Page
