TAP-103: Trouble Clearing 365-575-102
Page2of4 Issue8.0,July2002
Figure 1 – Example of Network Alarms Report using Release 6 or Higher.
6. Referring to the topmost entry in the Network Alarms Report obtained in Step
4, is there any text in the Event Description field?
If YES, then continue with Step 7.
If NO, then continue with Step 9.
NOTE:
The condition to be cleared is at a remote FT-2000 Repeater Bay/Shelf.
7. Referring to the topmost entry in the Network Alarms Report obtained in Step
4, issue a Trouble Report to the FT-2000 Repeater Bay/Shelf location with the
indicated Source Address. The Trouble Report should include the text from
the Event Description field.
8. STOP! YOU HAVE COMPLETED THIS PROCEDURE.
NOTE:
The Target ID (TID) of the local NE appears at the top of the CIT screen
between the NE name and LOCAL ONLY (or LOCAL).
NOTE:
Depending on the software release running in the local FT-2000 NE, the column
in the Network Alarms Report indicating the TID associated with a particular
condition may be labeled TID as in Figure 1 or Source Address.
MINOR Lucent Technologies FT-2000 6.0.0-ADR Delta-2 LOCAL ONLY
Delta-2 95-01-19 23:15:15 EST
M Retrieve-Network Alarms: COMPLD
/* Network Alarms Report
==========================================================================
System Date Time TID Product Local
Alarm Type Ring
==========================================================================
MN 01-19 21:18:47 Delta-2 FT-2000 Yes
MN 01-19 21:18:27 Delta-3 FT-2000 Yes
MN 01-19 21:20:57 Echo-1 DDM-2000 No
*/
