TAP-103: Trouble Clearing 365-575-102
Page4of4 Issue8.0,July2002
16. Obtain the appropriate reference DDM-2000 User/Service Manual as follows:
• 363-206-202 for DDM-2000 OC3 for Releases 2 through 7.2
• 363-206-280 for DDM-2000 OC3 for Release 8 and Higher
• 363-206-207 for DDM-2000 OC12/OC12 Regenerator for Releases 1
through 3.1
• 363-206-290 for DDM-2000 OC12 for Release 5 and Higher
17. Locate the appropriate task to be cleared from the trouble clearing index (IXL)
of the User/Service Manual based on the alarm level obtained from the report
in Step 4.
Nice to Know: The IXL lists tasks according to alarm level as follows:
18. STOP! YOU HAVE COMPLETED THIS PROCEDURE.
19. Issue a Trouble Report to the remote FT-2000 or DDM-2000 NE.
20. STOP! YOU HAVE COMPLETED THIS PROCEDURE.
21. Is the NE ACTY LED lighted on the user panel?
If YES, then continue with Step 22.
If NO, then STOP! YOU HAVE COMPLETED THIS PROCEDURE.
NOTE:
The trouble to be cleared is at the local FT-2000 NE.
22. Is the USE CIT LED lighted on the local user panel?
If YES, then go to TAP-102.
If NO, then go to TAP-101.
23. STOP! YOU HAVE COMPLETED THIS PROCEDURE.
SystemAlarm DDM-2000OC3
DDM-2000
OC12/OC12 Regenerator
CR Tap-101 Tap-101
MJ Tap-102 Tap-102
MN Tap-112 Tap-112
To Next Page
