TAP-116: Trouble Clearing 365-575-102
Page2of4 Issue8.0,July2002
NOTE:
pack identified in the Alarm and Status Report failed to clear the trouble
indication.
2. At the CIT, select Retrieve-Equipment to obtain an Equipage and Version
Report.
3. Referring to the entry in the Equipage and Version Report for the circuit pack
just replaced, note the type and slot address of the alternative replacement cir-
cuit pack (shown as alternative CP in the report).
4. Obtain a circuit pack of the type identified in Step 3 and install it in the slot
address identified in Step 3 (replacing an apparently good circuit pack).
Reference: DLP-514
5. Is the FAULT LED lighted on the
original replacement circuit pack
?
If YES, then go TAP-108.
If NO, then continue with Step 14.
6. Find the original circuit pack in the first column of Table A.
Table A - Circuit Pack Replacements
Original Alternative Replacement Circuit Pack Order
Circuit
Pack1 2345 6 7
DS3* LNCTL SYSCTL SYSMEM TRMTR RCVR DS3 —
LAA14 OW LAA14 OW — — — — — —
LNCTL SYSCTL SYSMEM TRMTR RCVR TG3 DS3/STS1E LSSW
LSSW LNCTL SYSCTL SYSMEM TRMTR RCVR DS3/STS1E —
OC3 LNCTL SYSCTL SYSMEM TRMTR RCVR TOHCTL OC3
OC12 LNCTL SYSCTL SYSMEM TRMTR RCVR TOHCTL OC12
OHCTL SYSCTL SYSMEM TRMTR RCVR DS3/STS1E — —
RCVR LNCTL SYSCTL SYSMEM TG3 DS3/STS1E/OC3 — —
REGENR REGENR SYSCTL SYSMEM — — — —
STS1E* LNCTL SYSCTL SYSMEM TRMTR RCVR STS1E —
SYSCTL SYSMEM — — — — — —
SYSMEM SYSCTL — — — — — —
TG3 LNCTL SYSCTL SYSMEM TRMTR RCVR DS3/STS1E —
TOHCTL SYSCTL SYSMEM TRMTR RCVR OC3 — —
TRMTR LNCTL SYSCTL SYSMEM TG3 DS3/STS1E/OC3 — —
* Remember to replace the protection circuit packs.
