TAP-148: Trouble Clearing 365-575-102
Page2of2 Issue8.0,July2002
6. Replace the shelf cover.
Reference: DLP-511
7. STOP! YOU HAVE COMPLETED THIS PROCEDURE.
8. Obtain the type of circuit pack determined from office records and install it in
the appropriate slot. As required, make the appropriate optical connections on
the OC-3, IS-3, OC-12, RCVR, TRMTR, or REGENR circuit pack(s).
Reference: DLP-514
9. Wait for the time indicated in Table B:
* Inserting an LNCTL circuit pack starts a mini reset that can take up to 10 minutes to complete. During this time,
LEDs on other circuit packs will be lighted.
†When a TG3 circuit pack is first inserted, it will be switched out of service until it warms up. This can take as
long as 5 minutes. You can confirm that it is in the standby state by using the FAULT-Retrieve-State command
for the TG slot.
10. Is the FAULT LED lighted on the replacement circuit pack?
If YES, then replace shelf cover and go to Trouble Clearing: IXL-001.
If NO, then continue with Step 11.
11. Replace shelf cover.
Reference: DLP-511
12. Is the NE ACTY LED lighted at the user panel.
If YES, then go to Trouble Clearing: IXL-001.
If NO, then STOP! YOU HAVE COMPLETED THIS PROCEDURE.
Table B - Mini Reset Waiting Times
CP Inserted Waiting Time
LNCTL * 10 minutes
OHCTL 5 minutes
TG3 †5 minutes
TOHCTL 5 minutes
All Others 35 seconds
