Lucent Technologies FT-2000 OC-48 User Manual

Platform Descriptions
Issue 8.0 July 2002
3-17
High-Speed Shelf 3
Purpose of High-Speed Shelf 3
The High-Speed Shelf
*
serves as an interface for the OC-48 high-speed lines 1W
and 1E. The High-Speed Shelf (Figure 3-10) consists of the fully connectorized
interconnection panel, a filter panel, and eight circuit pack slots. It measures 21.5
inches high by 21.5 inches wide by 12 inches deep and fits in a standard 23-inch
wide network bay framework.
High-Speed Shelf Circuit Packs 3
The High-Speed Shelf (Figure 3-10) provides the following circuit pack slots:
■ TRMTR 1W: One slot is provided for the 739B2
†
, 739C2
†
, 739E[1-16],
739H[1-16], 739J2
†
, 739J3
†
,739R2
†
, 739S2
†
, 739B4, 739J4, 739B5,
739C5, 739J5, 739P5, 739R5, or 739S5 OC48 Transmitter, Add/Drop
[OC48 TRMTR (A/D)] circuit pack for OC-48 high-speed line 1W. The
739J3
†
OC48 TRMTR (A/D) circuit pack is compatible with
Release 5.0.1-ADR or later software. The 739R2
†
and 739S2
†
OC48
TRMTR (A/D) circuit packs are compatible with Release 6.0.0-ADR or later
software. The 739B4, 739J4, 739B5, 739C5, 739J5, 739P5, 739R5, and
739S5 OC48 TRMTR (A/D) circuit packs are compatible with
Release 7.0.0-ADR or later software. The 739E[1-16] circuit packs are
compatible with Release 7.2.0 and later software.
■ RCVR 1W: One slot is provided for the 839B2
†
, 839B4B, 839B5, or 839E5
OC48 Receiver, Add/Drop (OC48 RCVR [A/D]) circuit pack for OC-48 high-
speed line 1W. The 839B4B and 839B5 OC48 RCVR (A/D) circuit packs
are compatible with Release 7.0.0-ADR or later software. The 839E5 circuit
pack is compatible with Release 7.2.0 and later software.
■ LNCTL: One slot is provided for the LAA28 Line Controller — 4 Megabyte
(LNCTL [4 MEG]) circuit pack.
■ OHCTL 1W: One slot is provided for the LAA22 Overhead Controller —
Terminal (OHCTL [TERM]) circuit pack.
■ OHCTL 1E: One slot is provided for the LAA21 Overhead Controller —
Terminal [OHCTL (TERM)] circuit pack.
TRMTR 1E: One slot is provided for the 739B2
†
, 739C2
†
, 739E[1-16],
739H[1-16], 739J2
†
, 739J3
†
, 739R2
†
, 739S2
†
, 739B4, 739J4, 739B5, 739C5,
739J5, 739P5, 739R5, or 739S5 OC48 Transmitter, Add/Drop [OC48 TRMTR (A/
D)] circuit pack for OC-48 high-speed line 1E. The 739J3 OC48 TRMTR (A/D)
circuit pack is compatible with Release 5.0.1-ADR or later software. The 739R2
†
and 739S2
†
OC48 TRMTR (A/D) circuit packs are compatible with
* The High-Speed Shelf is used only on an FT-2000 OC-48 Add/Drop-Rings Terminal for
two-Fiber Rings equipped with the J68974A FT-2000 OC-48 Lightwave Terminating Bay.
† These transmitters and receivers are DA effective 06/30/97.
