The filter panel (Figure 3-12) provides −48 V power filters, a power on (PWR ON)
LED, and an electrostatic discharge jack for the High-Speed Shelf. For more
information about the filter panel, refer to Section 6, "Operations Interfaces."
Figure 3-12. Filter Panel (High-Speed Shelf and Enhanced
High-Speed Shelf)
PWR
ON
ESD WRIST
STRAP GROUND
Identification
Label
Line
LINE
LINE
NO. = 1W
NO. = 1E
-48 V Power On
