Issue 8.0 June 2002 xxi
Figures
5-19 Example of a Ring Application with One Node
Provisioned Externally Timed and All Other Nodes
Provisioned Line Timed (Without Timing Drops) 5-32
5-20 Example of a Ring Application with Two Nodes
Provisioned Externally Timed and All Other Nodes
Provisioned Through Timed or Externally Timed (Without
Timing Drops) 5-33
5-21 Example of a Ring Application with
Three Nodes Provisioned Externally Timed
and One Node Provisioned Line Timed (Without
Timing Drops) 5-34
5-22 Example of a Ring Application with One Node Provisioned
Externally Timed and All Other Nodes Provisioned
Line Timed (With Two Timing Drops) 5-35
5-23 Example of a Ring Application with One Node Provisioned
Externally Timed and All Other Nodes Provisioned
Through Timed (with Timing Drops) 5-36
5-24 Example of a Ring Application with One Node Provisioned
Externally Timed and All Other Nodes Provisioned Through
Timed or Externally Timed (with Timing Drops) 5-37
5-25 Example of a Ring Application with All Nodes Provisioned
Externally Timed (with Timing Drops) 5-39
5-26 Example of a Timing Loop Resulting from Incorrect
Provisioning 5-40
5-27 Example of a Timing Loop Resulting from Inconsistent DS1
Timing Interfaces 5-41
5-28 Example of a Ring Application with All Nodes Provisioned
Externally Timed (with External Timing Emulation Cable) 5-42
6 Operations Interfaces
6-1 Remote Access Using the OC-48 Section Orderwire 6-11
6-2 User Panel (Low Speed Shelf - System Controller and
Repeater Shelf - System Controller) — Cabled Version
(Before 06/97) 6-13
