DS3 Termination
- Violation Monitor Removal [VMR],VM,CC w/AIS, and CIT CONFIGURATION- CONFIGURATION-
Mode CC w/o AIS Set-T3
[ENT-rr]
Retrieve-T3
[RTRV-rr]
- LBO (Electrical) In, Out Termination None None
Cable (Manually Installed)
EC-1 Termination¶
- LBO (Electrical) In, Out Termination None None
Cable (Manually Installed)
OC-48 Termination
- LBO (Optical) 0,5,10,15,or 20 dB Lightguide None None
Jumper (Manually Installed) (Stamping on LBO)
OC-3 Termination***
- LBO (Optical) 0 dB, 7.1 dB Lightguide None None
Jumper (Manually Installed) (Stamping on LBO)
OC-3 Protection Mode***
(From OC3) [0x1], 1+1 CIT CONFIGURATION- CONFIGURATION-
(From OC48) Set-OC3
[ENT-rr]
Retrieve-OC3
[RTRV-rr]
OC-12 Termination****
- LBO (Optical) 0 dB, 7.1 dB Lightguide None None
Jumper (Manually Installed) (Stamping on LBO)
OC-12 Protection Mode****
(From OC12) [0x1], 1+1 CIT CONFIGURATION- CONFIGURATION-
(From OC48) [0x1], 1+1 Set-OC12
[ENT-rr]
Retrieve-OC12
[RTRV-rr]
Alarm Levels
- DS3 Alarm Level
(Incoming Signal)
[CR], MJ, MN, NA, NR CIT CONFIGURATION-
Set-T3
[ENT-rr]
CONFIGURATION-Re
trieve-T3
[RTRV-rr]
- EC-1 Alarm Level¶
(Incoming Signal)
[CR], MJ, MN, NA, NR CIT CONFIGURATION-S
et-EC1
[SET-ATTR-rr]
CONFIGURATION-Re
trieve-EC1
[RTRV-ATTR-rr]
- OC-3 Alarm Level***
(Incoming Signal)
[CR], MJ, MN, NA, NR, NO CIT CONFIGURATION-S
et-OC3
[SET-ATTR-rr]
CONFIGURATION-Re
trieve-OC3
[RTRV-ATTR-rr]
- OC-12 Alarm Level****
(Incoming Signal)
[CR], MJ, MN, NA, NR, NO CIT CONFIGURATION-S
et-OC12
[SET-ATTR-rr]
CONFIGURATION-Re
trieve-OC12
[RTRV-ATTR-rr]
Performance Monitoring
- DS3 Signal Degrade
Threshold
10
-3
,[10
-6
]CITCONFIGURATION-S
et-T3
[SET-ATTR-rr]
CONFIGURATION-Re
trieve-T3
[RTRV-ATTR-rr]
Table 8-5. Provisionable Parameters (FT-2000 OC-48 Add/Drop-Rings Terminal) (Contd)
