NTP-009: Acceptance 365-575-102
Page 4 of 12 Issue 8.0, July 2002
15. At the FT-2000 primary node P, execute a manual
DRI switch for each path being tested. Use the
FAULT-Switch-Path-STS3(or STS1)-Manual
command for the appropriate line(s) and tributary(s).
16. Repeat Steps 12 through 14 for each path being
tested.
17. At the FT-2000 primary node P, reset the manual
DRI switch for each path being tested. Use the
FAULT-Switch-Path-STS3(or STS1)-Reset
command for the appropriate line(s) and tributary(s).
18. Verify that there are no alarm or status conditions in
the ring.
19. This completes testing path integrity (Figure 2) in the
local FT-2000 ring. If the external network is
non-Lucent (another vendor), refer to local
maintenance procedures to test path integrity in that
network. If the network is a DDM-2000 ring, refer to
the appropriate manual as follows:
63-206-202 for DDM-2000 OC3 for Releases 2 through 7.2
63-206-280 for DDM-2000 OC3 for Release 8 and Higher
63-206-207 for DDM-2000 OC12/OC12 Regenerator for Releases 1
through 3.1
63-206-290 for DDM-2000 OC12 for Release 5 and Higher
20. The local FT-2000 ring has two DRI cross-connections to the outside. Both DRI
cross-connections terminate directly to test sets.
Verify that there are no alarm or status conditions in
thering(Figure3).
21. At the transmit test set, insert a verifiable signal for
each path being tested.
22. At the receive test set, verify the detection of the
inserted signal on each path being tested.
DO ITEMS BELOW IN ORDER LISTED . . . . . . . FOR DETAILS, GO TO
