NTP-002: Circuit Order 365-575-102
Page2of4 Issue8.0,July2002
Obtain the circuit order instructions to add a DS3 or
EC1 port(s) and note the assigned address. A
point-to-point network address requires a line, slot,
and port(s) assignment. A ring network address
requires a slot and port(s) assignment.
—
2. If required, connect and condition the craft interface
terminal (CIT).
DLP-501
3. At the CIT, select
CONFIGURATION-Retrieve-Equipment, then LS
INTFC and execute to obtain an Equipage and
Version Report. Section 11 shows an example of the
report.
—
4. Determine from the report if the DS3 or STS1E
circuit pack is already present in each slot associated
with a DS3 or EC1 port to be added. A circuit pack is
in the slot if the type of circuit pack is indicated in the
Circuit Pack column of the report.
If circuit pack(s) is present in the slot(s),then
continue with Step 10.
If circuit pack(s) is not present in the slot(s),
then continue with Step 5.
5. Remove the appropriate low-speed shelf cover. DLP-511
6. If necessary, remove the apparatus (circuit pack)
blank(s) from the slot(s) requiring new circuit pack(s).
DLP-533
7.
NOTE:
For circuit pack and software compatibility, refer to Table 7-1 in Section 7,
"Circuit Pack Description."
NOTE:
A protection circuit pack of the same type (DS3 or STS1E) as a new
service electrical low-speed circuit pack must be installed in one of the
protection slots (P1 or P2) if low-speed protection is desired.
DO ITEMS BELOW IN ORDER LISTED . . . . . . . . FOR DETAILS, GO TO
