Parker Compax3 Fluid T40

Parker EME
Setting up Compax3
192-121102 N04 June 2008 125
Object 2250.17: Positive limit I-term
Object name
C3Plus.PressureController_1_PosLimit_IPart
Object No. 2250.17 HEDA-channel
no
Access:
Read/write
Valid after:
VP
CodeSys object:
yes
CodeSys format:
REAL
Unit
%
Minimum value
%
Maximum value
%
Remark:
CAN No.
-
PD object:
no
Profibus-No. (PNU)
-
Bus format:
I32
Object 2250.18: Negative limit I-term
Object name
C3Plus.PressureController_1_NegLimit_IPart
Object No. 2250.18 HEDA-channel
no
Access:
Read/write
Valid after:
VP
CodeSys object:
yes
CodeSys format:
REAL
Unit
%
Minimum value
%
Maximum value
%
Remark:
CAN No.
-
PD object:
no
Profibus-No. (PNU)
-
Bus format:
I32
Object 2250.19: D-term
Object name
C3Plus.PressureController_1_Derivative_Part_KFd
Object No. 2250.19 HEDA-channel
no
Access:
Read/write
Valid after:
VP
CodeSys object:
no
CodeSys format:
REAL
Unit
%s/pres
Minimum value
%s/pres
Maximum value
%s/pres
Remark:
CAN No.
-
PD object:
no
Profibus-No. (PNU)
-
Bus format:
I32
Object 2250.8: Delay T1
Object name
C3.PressureController_1_TimeDelay_DT1_T1
Object No. 2250.8 HEDA-channel
no
Access:
Read/write
Valid after:
VP
CodeSys object:
no
CodeSys format:
INT
Unit
us
Minimum value
250 us
Maximum value
us
Remark:
PID force controller 1 delay time constant of the D-term T1
Influences the D-term of the controller
CAN No.
-
PD object:
no
Profibus-No. (PNU)
-
Bus format:
U32
