Parker EME
Motion control
192-121102 N04 June 2008 253
Direct coupling (CouplingMode = 0)
M
S
Sa
ST
MT
C3_CamIn.Execute
ME
Sa: current slave position
MT: Master clock distance
ST: Slave clock distance
After Execute of C3_CamIn the slave will only couple in from the master coupling
position ME.
In order to avoid velocity jumps, the curve should have an initial gradient (slope) of
0.
