Configuration
6-50 Software Installation & Configuration
Note A Bed can be overviewed by a maximum of 4 Clients.
To assign a bed to a Patient Sector:
• Click on a Bed label in the Available beds list.
• Move the cursor to the desired Patient Sector.
• Click the mouse button when the cursor is over the desired Patient Sector. The Bed
label will then appear in that Sector.
Notes When the cursor moves over a Patient Sector with no bed assigned, it shows a single bed
icon.
When the cursor moves over a Patient Sector with a bed already assigned, it shows a 2-bed
icon.
If a Bed label is replaced, it will reappear in the Available beds list.
To remove a bed from a Patient Sector:
• Click on the Unassign icon at the bottom of Available beds.
• Move the cursor to the Patient Sector where the Bed is to be removed.
• Click the mouse button and the Bed label in that Patient Sector will be removed and
reappear in the Available beds list.
Notes When the Unassign cursor moves over a Patient Sector with no bed, it shows a circle with a
slash.
When the Unassign cursor moves over a Patient Sector with a bed assigned to it, it shows a
single bed icon with an X.
• Clicking OK stores the bed assignments and returns to the Bed Config window where
the new assignments appear in the Sector column of the Monitor/Overview Beds
field.
• Clicking Cancel returns to the Bed Config window and no bed assignments have
been changed.
Note If Dual Resting Display is checked, the top half of this screen will show the Patient Sectors
that will appear on Display 1, and the bottom half, those that will appear on Display 2.
Display 1 indicates the color (green) of Patient Sectors on Display 1.
Display 2 indicates the color (magenta) of Patient Sectors on Display 2.
Unassign button is for removing a bed from a Patient Sector. To remove a bed:
To Next Page
