Configuration
Software Installation & Configuration
6-51
• Click on the Bed Label in the Monitor/Overview Beds field to highlight it for
removal.
•Click Unassign and that bed is removed.
Procedure The procedure for configuring the Bed Config window is as follows:
Step 3. Select the desired Fast Alarm Display option -- Disabled, Red and Yellow, or
Red Only.
Step 4. Select the correct Central Station: # for this device for Information Centers. This
should have already been set on the Network Configuration page at the Database
Server, or earlier in the configuration on a Information Center without a Database
Server.
Step 5. Verify that entries in the SCC: and clinical Unit fields of Associations are correct.
Step 6. Verify the entry in the Monitoring: box is correct for the Unit listed above.
Step 7. Select the correct
# of Patients:
# Columns of Patient Sectors
# of Waves Per Sector
and whether to Show Alarm Limits in the Setup Sector Layout fields whether the
Dual Resting Display option should be enabled.
Note The number of waves can be 3 for 4 Patient Sectors, 2 for 6 - 12 Patient Sectors, 1 for 16
Patient Sectors, and 2 for 16 Patient Sectors with Dual Resting Display enabled.
Step 8. Verify the desired Patient Sector layout (# of Patients and # Columns) in the
Layout preview display.
Step 9. Click on Assign to access the Resting Display window.
Step 10. Assign Beds from the Available beds: field to Patient Sectors as follows:
• Click on a Bed label in the Available beds list.
• Move the cursor to the desired Patient Sector.
• Click the mouse button when the Bed label is over the desired Patient Sector. The
Bed label will then appear in that Sector. If a Bed label is replaced, it will reappear in
the Available beds: list.
When Beds have been assigned to all Patient Sectors:
Step 11. Click OK to return to the Bed Config window.
Step 12. Click N
ext> to commit the changes and advance to the next configuration window.
