Configuring the System
8-10 Start-up and Configuration
Step 6. Click on Properties to bring up the New Connection Properties window of
Figure 8-4.
Figure 8-4 New Connection Properties Window
Step 7. The Connect Using: field shows the Modem Manufacturer & Model #.
Step 8. Click Cancel to return to the New Connection - HyperTerminal window of
Figure 8-3.
Step 9. Follow the Action steps in Table 8-1 for your Model PC or server to verify the
modem connection and dial-in access:
Table 8-1. Modem Test Procedure
Model:
Action
D5000A
P2478U
P2478W
M3168A
Notes
Type:
Press Enter
AT&F1 resets the modem to factory defaults
Response if OK OK
Type:
Press Enter
ATM0 - last character is a 0 (zero)
- turns the speaker off
Response if OK OK
Type:
Press Enter
AT&T8 performs local analog loopback with self-test
Response if OK OK it is possible to include a blank line before OK
