• The Reps of Inertial Steps is greatly increased. It could be set to take a specific number of steps, or
simply set to a large number because this Approach Procedure is meant to be stopped manually.
F.2.2.4. Beetle Fast Out
The Beetle Fast Out Procedure is almost identical to the Beetle Single Step Out Procedure. The
differences are usually:
• The Value (amplitude) of the Ramp Legs Up item is increased to create bigger steps. Remember to
set a positive polarity for the Value of the Ramp Legs Up item.
• The Reps of Inertial Steps is greatly increased. It should be set to take a specific number of coarse
steps away from the sample.
F.2.2.5. *Z Beetle Approach Slow*
Figure F.5. Beetle Slow Approach Procedure
F.3. RHK Pan - UHV900
This section will describe the Approach Procedures for the RHK Pan.
F.3.1. Confirm Connections to Microscope
