Acquire Spectroscopy Data

Note

Please note that the only function of the LockIn 0 component is to provide a tuned filter that is

tuned to the frequency of the small Bias Voltage oscillation. This filter must be adjusted 2 ways,

first by setting the frequency to the CH1 Drive frequency, then by adjusting the Phase Offset so

that the maximum signal is passed through the filter. This tuning adjusts LockIn 0 to cancel out

the delays and phase shifts in the Oscillation signal that is going through the experimental

apparatus, compared to the reference signal inside the hardware.

Note

Support for Interferometer Feedback has been added in the Mode Selection box

Spectroscopy. An example plot is rendered below. Please refer to the Interferometer Quick

Start Guide for more information.

Figure 6.14. Interferometer Feedback
