STRASBAUGH, INC.
7AF SECS/GEM Interface Ver. 1.9 February 19, 2002 6-13
Strasbaugh Confidential
6-13
When the Equipment receives a good S2F31, it sets its internal clock/calendar. When receiving S2F31, the Equipment
will discard an invalid date or time. For example, if the date is good but the time is bad, the Equipment sets its date but
not its time.
6.32 S2F32 - Date and Time Acknowledge
S2F32 * H<-E
<B [1] TIACK> . * TIACK - Acknowledge Code
TIACK Description
0x00 Normal. Everything correct.
0x01 Invalid Date and/or Time.
6.33 S2F33 - Define Report
S2F33 W * H->E, Multiblock
<L [2]
<U4 DATAID> * DATAID
<L
<L [2]
<U4 RPTID> * Report ID
<L
<U4 VID> * Variable ID
...
>
>
...
>
> .
The Host specifies one or more Report IDs, and defines which Variables should be included in each report.
If S2F33 is multi-block, the Host may optionally send the S2F39/S2F40 Inquire/Grant Transaction before sending S2F33,
but this Equipment does not require it.
The Equipment ignores DATAID.
If the 7AF already contains existing Report Definitions, then this message can be used to download additional definitions
for RPTIDs not yet defined. The Host cannot download a new Report Definition for a RPTID for which a Report
Definition already exists in the Equipment. Instead, to change a Report Definition the Host must first delete the old Report
Definition and then send a new Report Definition for that RPTID.
The Host can delete selected report definitions and associated links in the Equipment by using the following specifications
in S2F33:
...
<L [2]
<U4 RPTID> * Report ID to delete
<L>
...
