STRASBAUGH, INC.
6-30 February 19, 2002 7AF SECS/GEM Interface Ver. 1.9
Strasbaugh Confidential
GRANT6 Description
0x00 Normal. Permission granted.
Other Permission not granted. The Equipment will not send
the following S6F3, S6F9, S6F11, or S6F13, and
will discard the data.
6.67 S6F9 - Event Report
S6F9 [W] * H<-E, Multiblock
<L [4]
<B [1] 00> * PFCD
<U4 DATAID> * DATAID
<U4 CEID> * Collection Event ID
<L
<L [2]
<U4 DSID> * DSID=RPTID Report ID
<L
<V> * Variable Value
...
>
>
...
>
> .
Note: This message is provided only for compatibility with older Host computers which do not support GEM. (See
section 2.7.2, "Gem Configuration".)
If the Equipment Constant "ConfigEvents" is set to "0", the Equipment sends S6F9 instead of the normal S6F11 Event
Report.
A Collection Event has occurred at the Equipment. The Host has enabled event reporting for this CEID (see S2F37). The
Host has set the Equipment Constant RpType to "False" (normal report format desired). The Equipment sends one or
more Event Reports which the Host has previously linked to that CEID (see S2F35). Each report contains specific
Variables which the Host has previously defined for that Report (see S2F33).
PCFD is always zero.
The Equipment generates a value for DATAID to uniquely identify this Conversation. If S6F9 is multiblock, the
Equipment first sends the S6F5/S6F6 Inquire/Grant transaction, and the DATAID in S6F9 will match DATAID in S6F5.
If the CEID is enabled, but no Reports are linked to this CEID, S6F9 has the following special format:
S6F9 [W] * H<-E
<L [4]
<B [1] 00> * PFCD
<U4 DATAID> * DATAID
<U4 CEID> * Collection Event ID
<L>
> .
Equipment Constant "WBitS6" controls whether the Equipment sends S6F9 with W-Bit "1" (Reply Expected) or "0" (No
Reply Expected).
6.68 S6F10 - Event Report Acknowledge
S6F10 * H->E
