38 SV I1 RT
COARSESPINDLESTATUS: Coarse Spindle Status
Value Meaning
-2 Idle
-1 Starting Grind Process
0 Grind Step 1
1 Grind Step 2
2 Grind Step 3
3 Dwell and unload grind force
4 Lift
5 Closing Grind Process
39 SV I1 RT
FINESPINDLESTATUS: Fine Spindle Status -
See Definition in “Coarse Spindle Status”
GEM Related Variables
The following are GEM variables that define the initial (power-up)
configuration of the GEM model.
40 EC U1 NU
INITCOMMSTATE: Initial Communications State -
Value Meaning
0 Disabled
1 Enabled
41 EC U1 NU
INITCONTROLSTATE: Initial Control State -
Value Meaning
1 Off-line
2 On-line
42 EC U1 NU
OFFLINESUBSTATE: Initial Off-line Substate
Value Meaning
1 Equipment Off-line
2 Attempt On-Line
3 Host Off-line
43 EC U1 NU
ONLINEFAILED:
Value Meaning
1 Equipment Off-line
2 Host Off-line
44 EC U1 NU
ONLINESUBSTATE: Initial On-line Substate
Value Meaning
4 Local
5 Remote
45 EC BOOL NU
RPTYPE: False - Normal Event Reports; True - Annotated Event Reports
46 EC U1 NU
CONFIGALARMS: 0 = S5F1; 1 = S5F71; 2 = S5F73;
47 EC U1 NU
CONFIGEVENTS: 0 = S6F9 or S6F3; 1 = S6F11 or S6F13;
48 EC U1 NU
WBITS5: 0 = W-Bit not set; 1 = W-Bit set;
49 EC U1 NU
WBITS6: 0 = W-Bit not set; 1 = W-Bit set;
50 EC U1 NU
WBITS10: 0 = W-Bit not set; 1 = W-Bit set;
51 EC U2 NU
HEARTBEAT: Time in seconds before sending S1F1; 0 = Off;
52 EC U2 NU
ESTABLISHCOMMUNICATIONSTIMER: Establish Communications
Timer, defines how often, in seconds, the equipment will attempt to establish
communication with the Host.
