Operations and Maintenance Manual Operator Functions
Version 1.2 - June 2004 8 - 59
START THE CYCLE
9. Start the cycle:
Operator Action Explanation/Screen Display
• Start Cycle Touch the "Start Cycle" button to begin the
cycle.
Notes: The bridge will move to its right position, and the left chuck will be
automatically cleaned.
After the chuck has been cleaned, the Start Cycle button will begin
flashing.
10. When the Start Cycle button begins flashing, place the appropriate dressing
disc (refer to Tools Required, above) in the center of the left work chuck:
a. Open the operator access door.
b. Place the dressing disc in the center of the left work chuck.
(For our example of dressing the coarse wheel, use the 500 Grit Dressing
Disc.)
c. Close the operator access door.
11. Continue the cycle:
Operator Action Explanation/Screen Display
• Start Cycle Touch the "Start Cycle" button to continue the
cycle.
