Strasbaugh nTellect (Model 7AF) Wafer Grinder
8 - 62 Version 1.2 - June 2004
CHUCK DRESSING AND TRUING
SELECT THE CHUCK AND THE TREATMENT DESIRED
For the procedure below, we will use dressing the left chuck as our example.
To dress the right chuck or true either the left or right chuck, make the desired
selections when the Select Chuck and Select Grind submenus are displayed.
Operator Action Explanation/Screen Display
3. Grind Chuck At the Dress Cycle menu, touch the "Grind
Chuck" button to display the Select Chuck
submenu.
4. Left At the Select Chuck submenu, touch the name of
the chuck (left or right) to be dressed. For our
example, touch "Left" to select the left work
chuck.
5. Dressing Touch the "Dressing" button at the Select Grind
submenu to select dressing.
To Next Page
