Operations and Maintenance Manual Operator Functions
Version 1.2 - June 2004 8 - 73
You Touch to Select Explanation/Screen Display
d. Measurement Touch the "Measurement" button on the
Reference Probes submenu to move the probes
down to measure the thickness of items resting
on the work chucks.
Note: The probe measurement values are shown in the status display
boxes at the right side of the menu screen.
e. Measurement To raise the probes, touch the "Measurement"
button again (toggle the Measurement button).
f. Cancel Touch the "Cancel" button to close the
Reference Probes submenu.
g. Quit Touch the "Quit" button to return to the Main
Menu.
4. Remove the item the work chuck:
a. Open the operator access door.
b. Remove the item
c. Close the operator access door.
