Strasbaugh nTellect (Model 7AF) Wafer Grinder
9 - 14 Version 1.2 - June 2004
CHOICES AVAILABLE AT THE WAFER RECIPES MENU
Buttons,
Submenus and
Icons
Functions
Quit
Save Grind
Data
Yes
No
Cancel
Touch the Quit button to return to the Main Menu.
The Save Grind Data message is displayed when the Quit button
is selected. At this location, you may:
Touch the Yes button to save your entries before returning to the
Main Menu.
Touch the No button to return to the Main Menu without saving
entries and changes you may have made to the recipe currently
displayed.
Touch the Cancel button to cancel your "quit" selection,
permitting you to continue to display the Wafer Recipes menu.
Select Wafer
Recipes
Recipe
Names
List
Ok
Cancel
Touch the Select Wafer Recipes button to display the list of
stored grind recipes.
Touch the name of the desired recipe to select it. The name of
the selected recipe will then be displayed in the Recipe Name
box.
Up to 12 different recipes may be stored at this location. You
may also change the preassigned names of any of the 12 recipes
here, provided the control computer's keyboard is plugged in,
permitting the entry of alpha characters. (Refer to the Physical
Description chapter of this manual for details on plugging in the
keyboard.)
Touch the Ok button to confirm your selection. When you
confirm your selection, the name you have chosen is transferred
to the recipe name box located at the upper center of the menu,
between the Coarse Grind and Fine Grind spreadsheets. At the
same time, the grind parameters of the recipe you selected are
transferred from memory to the screen.
Touch the Cancel button to cancel your selection and close the
Recipe Names List.
Wheel &
Chuck Recipes
Touch the Wheel & Chuck Recipes button to display the Wheel
and Chuck Recipes menu.
