Strasbaugh nTellect (Model 7AF) Wafer Grinder
1 - 4 Version 1.2 - June 2004
DOCUMENT CONVENTIONS
TOUCH SCREEN - OPERATOR AND MAINTENANCE PROCEDURES
Selections to be made on the control computer's touch screen are represented in the
manual in a two-column format with the screen symbol to be selected displayed in
bold type in the left column.
Screen symbols may be icons (pictures representing machine components) or buttons
containing text.
Example:
Move the bridge to its center position by following the steps below:
You Touch to Select Explanation/Screen Display
1. Machine Maint At the Main Menu screen, touch the "Machine
Maint" button to select the Machine
Maintenance menu.
Displays:
Machine Maintenance menu
2. C At the Machine Maintenance menu, touch the
"C” button on the bridge icon, located at the
upper left of the menu screen.
To Next Page
