Strasbaugh nTellect (Model 7AF) Wafer Grinder
11 - 34 Version 1.2 - June 2004
V. ADJUST THE UPPER SPINDLE ASSEMBLIES TO POSITIONS
PARALLEL WITH THE LOWER RIGHT SPINDLE
Tools Required
• 3/4-in. open end wrench
• 9/16-in. open end wrench or 1/4-in. hex key
UPPER LEFT SPINDLE
1. At the Home Machine menu, raise the probes:
Touch to Select Explanation/Screen Display
• Measure
Thickness At the Home Machine menu, touch the
"Measure Thickness" button to raise the probes.
CAUTION: Always confirm that the digital probes are in up position before
moving the bridge to avoid breaking them off!
