Strasbaugh nTellect (Model 7AF) Wafer Grinder
11 - 42 Version 1.2 - June 2004
Front to Rear
c. Locate the upper right spindle front to rear adjusting screw, a wedge
assembly extending horizontally from the rear of the upper right spindle
assembly.
Notes:
Access the adjusting screw through the door 19 opening.
The screw is labeled for easy identification.
d. Using a 9/16-in. open end wrench or a 1/4-in. hex key, rotate the screw as
needed to meet the goal.
Rotate the screw counterclockwise to lower the front (as viewed from the
front of the machine) of the grind wheel.
When Both Upper Spindles Are Parallel with the Lower Right Spindle
When both upper spindles are parallel with the lower right spindle, the upper spindles
can be used to reference the lower left spindle.
