Strasbaugh nTellect (Model 7AF) Wafer Grinder
11 - 50 Version 1.2 - June 2004
Touch to Select Explanation/Screen Display
a. Machine Maint At the Main Menu screen, touch the "Machine
Maint" button to select the "Machine
Maintenance menu.
Displays:
Machine Maintenance menu
b. Factor x 1000 Estimate the distance the bridge must move and
set the factor. For example, touch the "Factor x
1000" button to set the factor at .001 inches x
1000.
Notes:
.001 inches x 1000 = one inch of movement per
touch of the Right or Left Arrow button touch.
Readjust the factor, as shown below in Step 6.d.,
to avoid overtraveling and touching the sensor.
