Operations and Maintenance Manual Mechanical Maintenance Procedures
Version 1.2 - June 2004 11 - 53
13. Test the sensor position by moving the bridge away from and back toward the
sensor in small increments, finally positioning the bridge such that it covers
one-half of the sensor:
GOAL: The sensor's LED should be ON when the bridge covers
one-half of the sensor.
Touch to Select Explanation/Screen Display
Move the bridge away from the sensor:
a. Factor x 1000 Estimate the distance the bridge must move and
set the movement factor. For example, touch
the "Factor x 1000" button to set the factor at
.001 inches x 1000 (one inch).
b. ⇐ Touch the "Left Arrow" button on the bridge
icon at the top of the screen as many times as
needed to move the bridge away from the
sensor.
Note:
The sensor's light should turn OFF when the
bridge has been moved away.
Move the bridge toward the sensor:
c. Factor x 10
or
Factor x 1 At the Machine Maintenance menu, reduce the
factor as needed to move the bridge in smaller
increments.
d. ⇒ Touch the "Right Arrow" button on the bridge
icon at the top of the screen as many times as
needed to position the bridge over the sensor.
To Next Page
