Operations and Maintenance Manual Mechanical Maintenance Procedures
Version 1.2 - June 2004 11 - 75
Turn Vacuum ON
Follow the procedures found in the Operator Functions chapter of this manual.
END EFFECTOR VACUUM SEAL UP
1. At the Output Control/Input Status menu, turn vacuum ON to the robot end
effector:
Touch to Select Explanation/Screen Display
a. Machine Maint At the Main Menu screen, touch the "Machine
Maint" button to select the "Machine
Maintenance menu.
Displays:
Machine Maintenance menu
b. Inputs/
Outputs At the Machine Maintenance menu, touch the
"Inputs/Outputs" button to select the Output
Control/Input Status menu.
Displays: Output Control/Input Status menu
c. Robot icon At the Output Control/Input Status menu, touch
the "Robot" icon to select the Robot drop down
menu.
d. Vacuum ON/OFF Touch the "Vacuum ON/OFF" button until
Vacuum ON is displayed.
To Next Page
