Strasbaugh nTellect (Model 7AF) Wafer Grinder
11 - 90 Version 1.2 - June 2004
9. When the Test goal has been met, manually return the robot to its retracted
position:
a. Manually return the robot to its retracted position over the robot base.
b. Turn the robot servos back ON by following the procedure below:
Touch to Select Explanation/Screen Display
i. Robot icon At the Output Control/Input Status menu, touch
the "Robot" icon to select the Robot drop down
menu.
ii. Servos Touch the "Servos" button to select the Robot
Servos submenu.
iii. R ON/OFF Touch the "R ON/OFF" until
R ON is displayed, indicating the radial axis
servo is on.
iv. Theta ON/OFF Touch the "Theta ON/OFF" until
Theta ON is displayed, indicating the theta axis
servo is on.
v. Z ON/OFF Touch the "Z ON/OFF" until
Z ON is displayed, indicating the Z axis servo is
on.
