Operations and Maintenance Manual Mechanical Maintenance Procedures
Version 1.2 - June 2004 11 - 91
10. Remove the test wafer from the robot end effector:
a. While holding the wafer with one hand,
b. turn vacuum OFF to the end effector, releasing the wafer:
Touch to Select Explanation/Screen Display
i. Robot icon At the Output Control/Input Status menu, touch
the "Robot" icon to select the Robot drop down
menu.
ii. Vacuum
ON/OFF Touch the "Vacuum ON/OFF" button until
Vacuum OFF is displayed.
To Next Page
