Operations and Maintenance Manual Mechanical Maintenance Procedures
Version 1.2 - June 2004 11 - 95
6. Adjust the window position:
a. Open the four screw covers.
b. Loosen the four screws and screw cover pairs securing the plexiglass
window by rotating the screws counterclockwise.
c. Manually adjust the window position as needed to meet the goal.
d. Retighten the screws by rotating them clockwise.
7. Evaluate the window position after adjusting:
a. If the window position meets the goal, skip to Window Angle Adjustment,
below.
b. If the window position STILL does not meet the goal, correct it by
following the procedure in the Window Height Adjustment section,
immediately below.
B. Window Height Adjustment
1. Remove the plexiglass turret plate which forms the window of
door 1 (the cassette 1 door):
a. Open the four screw covers.
b. Remove the four screws and screw cover pairs securing the plexiglass
window by rotating the screws counterclockwise.
c. Lift off the plexiglass window and set it aside.
