Operations and Maintenance Manual Mechanical Maintenance Procedures
Version 1.2 - June 2004 11 - 97
b. Lotate the large adjusting screw centered on the locking collar clockwise
or counterclockwise as needed to meet the goal.
Note: The adjusting screw is hollow to accommodate the sensor
wires.
c. When the goal is met, rotate the clamp screws clockwise, tightening them
to 50%.
Note: When the clamp screws are sufficiently tightened, the platform
support will not wobble on the rotary actuator shaft.
Rotational Adjustment)
5. Using a 6-inch scale, measure the distance from each of the two clamp screws
nearest the door frame of the platform support to the outside edge of the
door frame.
GOAL: The two measurements should be equal (making the clamp
screws equidistant from the edge of the machine)
AND
each measurement should equal 1 7/8 in. when measured
from the outside diameter of the bolt (clamp screw) hole to
the outside edge of the door frame.
a. If the measurements meet the goal, skip to the Window Angle Adjustment,
below.
b. If the measurements do not meet the goal, correct the rotational
positioning by following the procedure in Step 6., immediately below.
