Operations and Maintenance Manual Mechanical Maintenance Procedures
Version 1.2 - June 2004 11 - 101
2. Read the level.
GOAL: The reading of the level (the bubble) should be centered
within the level's circle.
If the goal is not met, correct the position by following the procedure in Step
3., immediately below.
3. Correct the position of the platform by adjusting the three 1/4-20 hold down
screw and 1/4-20 adjusting setscrew pairs located below the platform:
For each pair requiring adjustment:
a. Using a 3/16-in. hex key, loosen the 1/4-20 hold down screw by rotating it
counterclockwise.
b. Using a 1/8-in. hex key, rotate the 1/4-20 adjusting setscrew as needed to
meet the goal.
c. When the goal has been met, retighten all the 1/4-20 hold down screws by
rotating them clockwise to firm.
4. Remove the level.
5. Rotate the turret to its load position (away from the robot):
Touch to Select Explanation/Screen Display
• Cassette 1
icon At the Output Control/Input Status menu, touch
the "Cassette 1" (Send1 Cassette) icon at the
Output Control/Input Status Menu to rotate its
platform.
