Strasbaugh nTellect (Model 7AF) Wafer Grinder
11 - 102 Version 1.2 - June 2004
6. Rotate the turret back to its robot position (facing the robot):
Touch to Select Explanation/Screen Display
• Cassette 1
icon At the Output Control/Input Status menu, touch
the "Cassette 1" (Send1 Cassette) icon at the
Output Control/Input Status Menu to rotate its
platform.
7. Recheck the adjustment by repeating Steps 1. and 2., above in this section.
Repeat the adjustment if needed to meet the platform leveling goal.
Cassette Platforms (Turrets) 2, 3, and 4
Repeat the Coarse Adjustment procedures for Cassette Platform 1, substituting
cassette 2 (and door 2), cassette 3 (and door 3), and cassette 4 (and door 4) for
cassette 1(and door 1) where appropriate.
