Operations and Maintenance Manual Mechanical Maintenance Procedures
Version 1.2 - June 2004 11 - 121
Change Procedure
Remove the Grind Wheel
1. Following the procedures found in the Basic Operation section of this chapter,
power up and home the machine.
2. Position the bridge as needed.
• To change the left grind wheel, move the bridge to its left position.
• To change the right grind wheel, move the bridge to its right position.
For our example, we will change the right grind wheel.
At the Machine Maintenance menu, move the bridge to its right position:
Touch to Select Explanation/Screen Display
a. Machine Maint At the Main Menu screen, touch the "Machine
Maint" button to select the Machine
Maintenance menu.
Displays:
Machine Maintenance menu
b. R Touch the "R" button, located at the upper left
of the menu screen, to move the bridge to its
right position.
(L = left)
3. Turn machine power OFF.
Note: Air must stay ON.
To Next Page
