Operations and Maintenance Manual Mechanical Maintenance Procedures
Version 1.2 - June 2004 11 - 147
C. ADJUSTMENT PROCEDURE
1. Open door 10.
Note: Opening door 10 will turn machine power off.
Up Position Switch
2. Using a 7/64-in. hex key, loosen the socket head capscrew securing the upper
switch to the cylinder by rotating it counterclockwise.
3. Slide the switch as far up as it will go.
4. Retighten the capscrew by rotating it clockwise.
Down Position Switch
5. Using a 7/64-in. hex key, loosen the socket head capscrew securing the lower
switch to the cylinder by rotating it counterclockwise.
6. Slide the switch as far down as it will go.
7. Retighten the capscrew by rotating it clockwise.
8. Close door 10.
9. Power up the machine.
