Strasbaugh nTellect (Model 7AF) Wafer Grinder
11 - 154 Version 1.2 - June 2004
c. Cassette 1
icon Touch the "Cassette 1" (Send1 Cassette) icon to
rotate its platform.
2. Read the screen status of the Send1 Robot Pos input:
GOAL: When the Send 1 turret is in load position the screen
display for Send1 Robot Pos should be green, indicating the
sensor is ON.
Record whether the goal is met or not met: _____________
Send 2 Cassette (Turret 2)
Repeat as for Send 1, substituting Send 2 for Send 1 where appropriate.
Record whether the goal is met or not met: _____________
Receive 1 Cassette (Turret 3)
Repeat as for Send 1, substituting Receive 1 for Send 1 where appropriate.
Record whether the goal is met or not met: _____________
Receive 2 Cassette (Turret 4)
Repeat as for Send 1, substituting Receive 2 for Send 1 where appropriate.
Record whether the goal is met or not met: _____________
