Operations and Maintenance Manual Software Calibration
Version 1.2 - June 2004 12 - 7
After referencing, the zero point is reestablished at the work chuck.
After power up and the initial referencing, for subsequent referencing, the count is
upward from the work chuck beginning with zero.
Upward movement of the spindles is always positive; downward movement is
always negative.
Note that negative numbers are always displayed in RED at the screen readout.
CHOICES AVAILABLE AT THE MACHINE MAINTENANCE MENU
Note: The machine must be HOMED before machine components can be moved
at this menu.
Buttons,
Submenus,
and Icons
Function(s)
QUIT
Touch the QUIT button to return to the Main Menu.
Inputs/
Outputs
Touch the Inputs/Outputs button to display the Output
Control/Input Status menu.
Machine Setup
Touch the Machine Setup button to display the Machine
(Calibration) Setup menu.
STOP
MACHINE
Touch the STOP MACHINE button to stop the movement of
the work chucks, grind spindles, fine z-axis, coarse z-axis,
and bridge.
