Strasbaugh nTellect (Model 7AF) Wafer Grinder
12 - 8 Version 1.2 - June 2004
Manual Control of Components
BRIDGE
Left/Right
Movement:
L
C
R
⇐
⇒
The buttons on the bridge icon, located at the upper left of
the menu screen, permit manual control of left and right
movement of the bridge.
Touch the L button to move the bridge to its left position.
Touch the C button to move the bridge to its center position.
Touch the R button to move the bridge to its right position.
Touch the Left Arrow button to move the bridge 0.001
inches to the left. Use the Left Arrow in combination with
the Factor buttons (see below) to move the bridge to the left
in larger increments.
Touch the Right Arrow button to move the bridge 0.001
inches to the right. Use the Right Arrow in combination with
the Factor buttons (see below) to move the bridge to the right
in larger increments.
Note: Before the bridge is permitted to respond to the arrow
keys, the control computer confirms that grind seals are
deflated, probes are up, grind wheels are up, and
conditioning arms are out of the way.
